The machine is properly designed, the function of each part shall meet the requirement of client, and have appropriate margin, it is stably and reliable.

Lubricating system is perfectly designed, which can guarantee the good lubrication of each operating parts.

The equipment is in sophisticated manufactured, the manufacturing accuracy and quality standards of all the spare parts should be in consistent with the relevant standards.

Equipment assembly shall be accurate which can ensure the flexible and stable movement of the transmission system.

Fine performance, easy to operate, sensitive and reliable operating system, and good maintainability.

Design of the electrical control system meets the movement requirements of all constitutions, and its quality is in line with the relevant quality standard and relevant national safety standards.

All outsourcing parts of the equipment shall be the qualified products purchased from the designated manufacturers which are certificated by the quality assurance system.

All the auxiliary electrical equipments outside the control cabinet shell shall have the reliable grounding protection, and each ground point shall not be tandem in connection.

All cables shall be reliable and insulative, and the place which has friction with the metal parts shall not be exposed, and the cable support should be moistureproof.

Tube diameter: φ25.4-219.3mm
Tube wall thickness: 2.0-10mm
Tube length: 25000mm
Tube material: carbon steel (SA106B, SA192, etc), Cr-Mo alloy steel (T11, T22, T23, T91, P11, P22, P23, P91 etc), austenitic stainless steel (TP316L, TP410, etc)

Steel strip width: 8-25.4mm
Steel strip thickness: 0.8-3.0mm
Serrated strip thickness: 0.8-1.5mm
Serrated height: 0-15mm
Steel strip material: carbon steel, low alloy steel, high alloy steel (11Cr), austenitic stainless steel

Fin tube length: 25000mm
Fin pitch: 3.4-16mm continuously adjustable
Min. distance from fin to tube end: 100mm

Conveyor height for fin tube: the height is adjustable, match with the height of tube conveyor

Working condition: 300 day/year, 3 shift/day, and continuous duty.

Working environment
power supply: 3 phase AC380V, fluctuation of electric network voltage ±15%; frequency 50±5%Hz
working environment temperature：－5℃～+45℃
relative humidity: ≤96%
compressed air supplied: 0.4～0.6MPa (including water and oil)
It can work 24 hours continuously and stably in the above mentioned working condition.
